Setting up an nginx Reverse Proxy with Docker

Introduction

In this tutorial, we will set up an nginx reverse proxy using Docker and docker-compose. This will allow us to route HTTP requests arriving through different subdomains to web services running in different Docker containers. We will also set up a LetsEncrypt CertBot to automatically create and renew TLS certificates.

Requirements

• Server (root or VPS)
• Working Docker installation
• Working docker-compose installation.

Step 1 - Define the services using docker-compose

Create a new YAML file reverse-proxy.yml and open it using an editor of your choice:

vim reverse-proxy.yml

Insert the following:

version: '3'

services:
    nginx:
        image: jwilder/nginx-proxy
        container_name: nginx-proxy
        restart: always
        logging:
            driver: "json-file"
            options:
                max-size: "50m"
                max-file: "1"
        ports:
            - '80:80'
            - '443:443'
        volumes:
            - conf:/etc/nginx/conf.d
            - certs:/etc/nginx/certs
            - vhost:/etc/nginx/vohost.d
            - html:/usr/share/nginx/html
            - dhparam:/etc/nginx/dhparam
            - '/var/run/docker.sock:/tmp/docker.sock:ro'

    nginx-proxy-le:
        image: jrcs/letsencrypt-nginx-proxy-companion
        container_name: nginx-proxy-le
        restart: always
        logging:
            driver: "json-file"
            options:
                max-size: "50m"
                max-file: "1"
        volumes:
            - conf:/etc/nginx/conf.d
            - certs:/etc/nginx/certs:rw
            - vhost:/etc/nginx/vhost.d
            - html:/usr/share/nginx/html
            - '/var/run/docker.sock:/var/run/docker.sock:ro'
        environment:
            NGINX_PROXY_CONTAINER: nginx-proxy

networks:
    default:
        external:
            name: compose-net

volumes:
    conf:
    vhost:
    html:
    certs:
    dhparam:

This docker-compose file will create two services: The nginx-proxy container will run the nginx reverse proxy, while nginx-proxy-le will manage LetsEncrypt's TLS certificates. Please note that the log files have a size limit to avoid running out of disk space. You can of course change this. The nginx config can be found in the conf Docker volume (though it should not be necessary to edit it manually).

Step 2 - Create the Docker network

Run the following Docker command:

docker network create compose-net

If you are currently not the root user and did not set up your user to use Docker, you may have to run this command with sudo privileges.

Step 3 - Deploy the services

Use docker-compose to deploy both containers and auto-create the Docker network and volumes:

docker-compose -f reverse-proxy.yml up -d

Just as in Step 2, you might need sudo privileges depending on your system setup.

Step 4 - Set up your web services

You can now set up your web services to be reachable under a given subdomain. Just define the subdomain you want to route to a service using the VIRTUAL_HOST environment variable. If you use a different docker-compose file for your services, make sure to use the same Docker network as for the reverse proxy:

## my-service.yml
version: '3'
services:
    whoami:
        image: jwilder/whoami
        environment:
          - VIRTUAL_HOST=whoami.your-domain.de

networks:
    default:
        external:
            name: compose-net

Make sure that your subdomain resolves to your server's public IP address, then deploy your web service:

docker-compose -f my-service.yml up -d

The LetsEncrypt companion container should now automatically request a TLS certificate and set up the reverse proxy in order to route requests to your service afterwards. Give it a few minutes (as key generation might take a while), then try reaching your service at whoami.your-domain.de (or whatever subdomain you used) from your web browser.

Conclusion

This fully automated setup makes it easy to deploy multiple web services without having to use multiple IP addresses. It also handles TLS certificates for you, making it easy to make services publicly available.
