Setup of Standalone Uptime Kuma on Ubuntu with a Reverse Proxy

Introduction

This tutorial describes how to set up an Uptime Kuma instance on Ubuntu 20.04. Uptime Kuma is a free and open source uptime monitor. It is a self-hosted alternative to services like Uptime Robot or StatusCake. It is available as a Docker image, but this tutorial describes how to set up an instance without Docker (as a standalone).

This tool is very useful for getting notified when a service is down.

The time needed to follow this tutorial is approximately 10 - 20 minutes.

The tutorial was tested on Ubuntu 22.04 (April 2023).

The tutorial uses the example ip 123.123.123.123.
This hostname needs to be replaced by the name of your own server when you perform the steps described below.
We will also use the domain example.com in this tutorial. Replace it with your own domain.

We will not use the installation script provided by Uptime Kuma, because it is sometimes buggy.

Requirements

For a 'small instance' (up to 20 monitored services) VPS 200 is sufficient.

I recommend setting up the instance on a VPS 200.
If you feel like the instance is slowing down, you can always update to a bigger server trough the CCP.

The server needs to have Ubuntu 20.04 and SSH already installed.

You will also need a domain. A domain used in a webhosting package is sufficient. (You can still use it for your webhosting, because we will use a subdomain.)

Step 1 - Finding out the IP of your server

1. Log in to the SCP (ServerControlPanel) under https://www.servercontrolpanel.de.
2. Click on the server you want to use.
3. If you are already on the "General" tab, you'll see a pane labeled "Network" in the bottom right corner.
4. Here you can find the IP of your server (under IPv4).
5. Write the IP of your server down.

Step 2 - Configuring DNS

1. Log in to the CCP (CustomerControlPanel) under https://www.customercontrolpanel.de.
2. In the sidebar on the left, click on "Domains".
3. Find the domain you want to use and click on the magnifying glass symbol next to it.
4. In the new window, click on "DNS".
5. Scroll down until there are empty fields.
6. In the first field, write your subdomain name (I recommend using "status").
7. In the dropdown menu, select A.
8. In the last field, enter the IP of your server (from Step 1).
9. Click on "Save DNS records".

Step 3 - Preparing the server

First you need to log in to your server via SSH, then follow these steps:

1. Enter sudo -s to get root privileges.
2. If asked for your password, enter it and press Enter.
3. Now enter apt update -y && apt upgrade -y to update the server.
4. If a pink window appears, press Enter once to continue.
5. Enter curl https://deb.nodesource.com/setup_16.x -o /tmp/nodesource_setup.sh && bash /tmp/nodesource_setup.sh to install NodeJS 16.
6. Enter apt install nodejs curl nginx git -y to install all the required software.
7. If a pink window appears, press Enter once to continue.
8. Enter npm install npm -g to update npm.
9. If a pink window appears, press Enter once to continue.
10. Enter npm install pm2 -g && pm2 completion install to install pm2 and its autocompletion.
11. Enter exit and press Enter to leave root privileges.

Step 4 - Installing Uptime Kuma

Enter the following command to install Uptime Kuma:

1. Enter git clone https://github.com/louislam/uptime-kuma.git to clone the repository.
2. Change directory by executing cd uptime-kuma.
3. Enter npm run setup to install all dependencies.
4. Now start Kuma by entering npm run start-server.

Once you see "Listening on 3001" in the terminal, go to your IP on Port 3001 (e.g. 123.123.123.123:3001) in your browser. If you see the Uptime Kuma setup screen, you have successfully installed Uptime Kuma. Please stop the server by pressing Ctrl + C in the terminal once. You have to wait a little while until the server stops.

Step 5 - Reverse Proxy with nginx

1. Enter sudo -s to get root privileges.
2. If asked for your password, enter it and press Enter.
3. Enter nano /etc/nginx/sites-available/uptime-kuma to create a new nginx config file.
4. Paste the following code into the file:

server  {
    listen 80;
    ## Remove '#' in the next line to enable IPv6
    ## listen [::]:80;
    server_name    sub.domain.com;
    location / {
        proxy_pass         http://localhost:3001;
        proxy_http_version 1.1;
        proxy_set_header   Upgrade $http_upgrade;
        proxy_set_header   Connection "upgrade";
        proxy_set_header   Host $host;
    }
}

5. Replace sub.domain.com with your subdomain (e.g. status.example.com).
6. Exit the file by pressing Ctrl + X and then Y and then Enter.
7. Enter ln -s /etc/nginx/sites-available/uptime-kuma /etc/nginx/sites-enabled/uptime-kuma to enable the config file.
8. Enter nginx -t to test the config file.
9. If you see test is successful, you can reload nginx by entering systemctl reload nginx.

Step 6 - Setting up Uptime Kuma to start on boot

We want to start Uptime Kuma automatically when the server starts.
This is useful when the server reboots, as we cannot monitor the server running Kuma. When it is restarted, Kuma will also be restarted.

1. Enter nano /etc/systemd/system/uptime-kuma.service to create a new systemd service file.
2. Paste the following code into the file:

[Unit]
Description=Uptime-Kuma - A free and open source uptime monitoring solution
Documentation=https://github.com/louislam/uptime-kuma
After=network.target

[Service]
Type=simple
User=[REPLACE_WITH_USERNAME]
WorkingDirectory=/home/[REPLACE_WITH_USERNAME]/uptime-kuma
ExecStart=/usr/bin/npm run start-server
Restart=on-failure

[Install]
WantedBy=multi-user.target

3. Replace [REPLACE_WITH_USERNAME] with the user under which you want to run Uptime Kuma (we don't want to run it as root, so please run it as your SSH login user or create a new user).
4. Exit the file by pressing Ctrl + X and then Y and then Enter.
5. Enter systemctl daemon-reload to reload the systemd daemon.
6. Enter systemctl enable uptime-kuma to enable the service.
7. Enter systemctl start uptime-kuma to start the service.

Step 7 - Setting up HTTPS

1. Enter snap install --classic certbot to install CertBot.
2. Enter certbot --nginx to start the CertBot setup.
3. I recommend using these settings:
   1. Enter your email address.
   2. Yes (Terms of Service)
   3. No (Advertisement)
   4. Press Enter to select the only option (your domain).
   5. This process can take a while, so please be patient.

Step 8 - Setting up the Firewall

We need a firewall to protect our server from unwanted connections.

We will use ufw (Uncomplicated Firewall) to set up the firewall, because it is easy to use and configure and is also pre-installed on Ubuntu.

1. Enter ufw allow ssh to allow SSH connections.
2. Enter ufw allow http to allow HTTP connections.
3. Enter ufw allow https to allow HTTPS connections.
4. Enter ufw enable to enable the firewall.
5. Press Y and then Enter to confirm.

Step 9 - Setting up Uptime Kuma

1. Open your browser and go to your subdomain (e.g. https://status.example.com).
2. You should see the Uptime Kuma setup screen.
3. Enter your username and password, also choose the right language. The username is case sensitive!
4. Click on "Create".
5. In the top right corner, click on the dropdown menu and select "Settings".
6. In the "General" tab under "Primary Base URL", click on "Auto Get" so that the URL is automatically set.

If this works, you should now restart the server and check if everything starts as it should. To do this, execute shutdown -r now. After executing the command, you can close the SSH connection.

Conclusion

Now you have successfully installed Uptime Kuma and set it up to start on boot.

From now on your Kuma instance will be available under your subdomain (e.g. https://status.example.com).

Thank you for using this tutorial!
